CPU | ARM Cortex-A7 Dual-Core |
GPU | ARM Mali400MP2 |
Comply with OpenGL ES 2.0/1.1 |
Video | HD H.264 2160p video decoding |
Multi-format FHD video decoding, including Mpeg1/2, Mpeg4 SP/ASP GMC, H.263, H.264, VP6/8, AVS jizun, Jpeg/Mjpeg, etc. |
BD Directory, BD ISO and BD m2ts video decoding |
264 High Profile 1080p@30fps or 720p@60fps encoding |
3840x1080@30fps 3D decoding, BD/SBS/TAB/FP supported |
Comply with RTSP, HTTP,HLS,RTMP,MMS streaming media protocols |
Display | Support multi-channel HD display |
Integrated HDMI 1.4 transmitter with HDCP support |
CPU/RGB/LVDS LCD interface |
Support CVBS/YPbPr/VGA |
Integrated TV decoder |
Camera | Integrated parallel 8-bit I/F YUV sensor |
Integrated 24-bit parallel YUV 444 I/F |
Support 5M CMOS sensor |
Support dual sensors |
Memory | DDR2/DDR3/DDR3L controller |
NAND Flash controller with 64-bit ECC |
Audio | Integrated HI-FI 100dB Audio Codec |
Dual MIC noise cancellation |
OS | Android 4.1/4.2 and above |
